UV/Vis Spectrophotometer: BLK-C-SR
| Dynamic Range: | 2000:1 with 6 decades |
| Optical Resolution: | see above |
| Detector Type: | 2048 pixel CCD, PDA opt. |
| Detector Range: | 200-1080 nm |
| Pixel Size: | 14 µm x 200 µm |
| Concave Grating: | Aberration corrected |
| Grating Type: | Holographic, 590 g/mm |
| Spectrograph: | f/2, Flat field - No mirrors |
| Order Sorting Filter: | Integrated multi-band |
| Signal to Noise: | 1000:1 CCD, PDA 2000:1 |
| Digitizer: | 16-bit |
| Dimensions: | 69 x 100 x 150 mm |
| Power Consumption: | 100 mA @ 5 VDC |
| Interface: | USB-2 |
| Data Transfer Speed: | 3x / 40x faster than USB-1 |
| Detector Integration: | 1 ms to 65 s |
| Slit Size Options: | 14, 25, 50, 100, 200 µm |
| Stray Light: | 0.02% at 435 nm; 0.2% at 200 nm |
| Fiber Optic Input: | SMA905 0.22 na single fiber |
| Operating Systems: | Windows XP/Vista/7 |
| Software Included: | SpectraWiz program & apps |
| Also Free Programs For: | LabView / VC / VBA / Delphi |
Vis/NIR Spectrophotometer: RED-DWARF-512
| Dynamic range: | 4000:1 with 5 decades |
| Resolving resolution: | 2.5nm with 25µm slit |
| InGaAs Detector: | 512 or 1024 pixels |
| Detector range: | 900-1700nm |
| Pixel size: | 25µm x 500µm |
| Pixel well depth: | 130 x10^8 electrons |
| Selectable well control: | 130 x10^8 or 5 x10^6 el. |
| Signal to noise: | 4000:1 with TEC cooling |
| Digitizer: | 16-bit |
| Dimensions: | 5"x3"x2" |
| Power consumption: | 1.5 Amps @ 5 VDC |
| Interface: | USB-2 |
| Data transfer speed: | 40x faster than USB-1 |
| Detector Integration: | 1 millisecond to 30 secs |
| Slit size options: | 25µm |
| Operating systems: | Windows XP/Vista/7 |
| Software included: | SpectraWiz programs & Apps |
| Also free programs for: | LabView, Excel+VBA, Delphi |
SL1-FILTER Tungsten Halogen
- 10,000 hour tungsten krypton bulb with 2800 degree Kelvin color temperature
- For process control and field portable applications from 350-2300nm
- 7-28 VDC input with 0.2% power regulation for bulb
- 12VDC @ 800ma wall power adapter included
- 5 minute stabilization, no fans, slot for filters
- Equalization filter flattens the response from 500-900nm allowing a larger reference at 400nm for color based applications
SL3:
- 15 Watt Deuterium light source
- 4000 hour Hamamatsu L2D2 bulb
- integrated 0.5inch diameter filter holder
Other Equipment
- Filter-U330: 0.5 inch diameter Hoya 330 UV filter for SL3 removes deuterium spikes
- LENS-DCX: Installs in SL3 filter base for 7-10x gain
- F400YBNIRUVSR: Armored 400µm fiber optic Y cable bundle, 0.5 meter, solarization resistant connects SL1 + SL3
- SMA-Splice: Used to adjoin two fiber optic cables
- F600-UVVIS-SR: Armored Solarization Resistant 600µm fiber optic cable - 2 meters
- F600-VISNIR: Armored fiber optic cable, 600µm core, 2 meter with black PVC jacket.
- R600-3-UVSRNIR: Trifurcated reflection probe, mixed SR/VIS fibers, 600µm read, black PVC monocoil jacket, enhanced connectors, 2 meters
- RS50: 50mm diameter White reflectance standard, halon >97%
- CUV1: 4-way fiber optic cuvette holder for measuring absorbance, transmittance, or fluorescence. Includes 2 Lens-Q-Col.
- RPH1: Reflectance probe holder block. Maintains 45 degree angle and user set distance from sample (0-3/4").
- RPH3: Reflectance Probe Holder stand for 90° angle measurements.
- IC-2: Miniature integrating sphere with 5/8" port - required for LED xy Chromaticity
Software
SpectraWiz: Real-time operating software for Windows 9x/XP includes
integrated applications for SpectroRadiometry*, traditional
Spectroscopy (absorbance/transmission/reflectance), CIELAB
colorimetry, LED color analysis*, ChemWiz chemical
concentrations, UVabc* monitors, episodic capture for time series
analysis. Includes software training videos on CDROM.
|
|
